WA 81

Name: WA 81
Brand: WAGNER

Automatic spray gun for the perfect internal coating of pipes. A uniform spray jet is generated by a disk nozzle in the internal mixing process. Axial connection arrangement for a smooth drawing process thanks to cylindrical geometries.

Request quote now

Benefits

The WA81 is particularly suitable for the precise internal coating of cylindrical geometries such as pipes. By using a disc nozzle in the internal mixing process, it produces a uniform, circular spray jet for optimum coating results.

The axial arrangement of the connections enables the spray gun to pull smoothly through the pipe during the coating process and ensures efficient application.

The 360° all-round spray function of the spray gun enables a comprehensive and even coating of the inside of the pipe.

Technical data

Material pressure

max. 6 bar

Sound level

83 dB(A)

Processable materials

Solvent-based, water-based

Nozzle sizes

0.5mm - 1.5mm

Operating temperature

max. 80°C

Product dimensions [LxWxH]

120x20x46mm

Weight [net/gross]

112g / 247g

Certifications

Customer references

Application examples from various industries will give you an insight into how our products and solutions are used in practice.

Go to customer references

Downloads

Operating manual WA 81

PDF | 1.44 MB
